Magnetic Assembly

Magnetic assembly combined by magnetic material with other components, for instance, plastic part, lamination stacks, metal part, etc.

We are able to provide magnetic assemblies:

- Stator and rotor with magnetic materials for pump, liner motors;

- Pot magnets by Sintered NdFeB magnet/ Ferrite magnet/Flexible magnets for home, office and fishing application;

- Other Customized magnetic assembly.

Features

u Professional team provide project developing supports

u State-of-the-art equipment and laboratories

u Supply magnetic simulation support

u Efficient automatic production line

Dimension for Fishing Magnets

Fishing Magnet
型号 Model	D (mm)	d (mm)	d1 (mm)	H (mm)	h (mm)	M	部件自重 Part Weight (g)	拉脱力 Breakaway (kg)	镀层 Coating
MGTNJ20	20	10	19	27	7	M4	27	11	Ni,Zn,Epoxy or Customized
MGTNJ25	25	12	22.5	32	8	M5	44	22	Ni,Zn,Epoxy or Customized
MGTNJ32	32	12	22.5	32	8	M5	59	32	Ni,Zn,Epoxy or Customized
MGTNJ36	36	15.5	27	38.5	8	M6	71	43	Ni,Zn,Epoxy or Customized
MGTNJ42	42	15.5	27	39.1	8.6	M6	98	65	Ni,Zn,Epoxy or Customized
MGTNJ48	48	19.5	34.5	47	11	M8	197	75	Ni,Zn,Epoxy or Customized
MGTNJ55	55	19.5	34.5	48	12	M8	278	95	Ni,Zn,Epoxy or Customized
MGTNJ60	60	19.5	34.5	51	15	M8	330	160	Ni,Zn,Epoxy or Customized
MGTNJ70	70	24.5	41	60.5	17	M10	608	200	Ni,Zn,Epoxy or Customized
MGTNJ75	75	24.5	41	61.5	18	M10	632	250	Ni,Zn,Epoxy or Customized
MGTNJ80	80	24.5	41	61.5	18	M10	821	280	Ni,Zn,Epoxy or Customized
MGTNJ90	90	24.5	41	61.5	18	M10	899	360	Ni,Zn,Epoxy or Customized
MGTNJ120	120	27.5	50	68.5	18	M12	1510	480	Ni,Zn,Epoxy or Customized
Note: Dimension can be customized, contact us for more details and informaiton.

Dimension for Pot Magnets

Pot Magnet
Model	D (mm)	d (mm)	d1 (mm)	H (mm)	Part Weight (g)	Breakaway (kg)	Coating
MGTNA12	12	3.5	6.5	4.5	4	2.5	Ni,Zn,Epoxy or Customized
MGTNA16	16	3.5	6.5	5	7	6	Ni,Zn,Epoxy or Customized
MGTNA20	20	4.5	8.6	7	14	11	Ni,Zn,Epoxy or Customized
MGTNA25	25	5.5	10.6	8	25	22	Ni,Zn,Epoxy or Customized
MGTNA32	32	5.5	10.6	8	42	32	Ni,Zn,Epoxy or Customized
MGTNA36	36	5.5	11.3	8	54	43	Ni,Zn,Epoxy or Customized
MGTNA42	42	6.5	11.3	8.6	78	65	Ni,Zn,Epoxy or Customized
MGTNA48	48	8.5	15.5	11	138	75	Ni,Zn,Epoxy or Customized
MGTNA55	55	8.5	14.5	12	2.5	95	Ni,Zn,Epoxy or Customized
MGTNA60	60	8.5	14.5	15	305	160	Ni,Zn,Epoxy or Customized
MGTNA70	70	10.5	16.5	17	485	200	Ni,Zn,Epoxy or Customized
MGTNA75	75	10.5	16.5	18	560	250	Ni,Zn,Epoxy or Customized
MGTNA80	80	10.5	16.5	18	668	280	Ni,Zn,Epoxy or Customized
MGTNA90	90	10.5	16.5	18	850	360	Ni,Zn,Epoxy or Customized
MGTNA120	120	12.5	22.5	18	1520	480	Ni,Zn,Epoxy or Customized
Note: Dimension can be customized, contact us for more details and informaiton.

Dimension for Hook Magnet

Hook Magnet
Model	D (mm)	d (mm)	M	h (mm)	h1 (mm)	H (mm)	Part Weight (g)	Breakaway (kg)	Coating
MGTNE10	10	6	M3	5	12.5	33	6	2	Ni,Zn,Epoxy or Customized
MGTNE12	12	6	M3	5	12.5	33	7	4	Ni,Zn,Epoxy or Customized
MGTNE16	16	6.5	M4	7	12.6	35	12	8	Ni,Zn,Epoxy or Customized
MGTNE20	20	6.5	M4	7	14	36	2`1	12	Ni,Zn,Epoxy or Customized
MGTNE25	25	7.5	M5	8	17	45	37	25	Ni,Zn,Epoxy or Customized
MGTNE32	32	10	M6	8	18	48	61	34	Ni,Zn,Epoxy or Customized
MGTNE36	36	10	M6	8	18	48	69	50	Ni,Zn,Epoxy or Customized
MGTNE42	42	10	M6	8,6	18	48	101	72	Ni,Zn,Epoxy or Customized
MGTNE48	48	12	M8	11	24	61	182	81	Ni,Zn,Epoxy or Customized
MGTNE55	55	12	M8	12	28	64.5	252	95	Ni,Zn,Epoxy or Customized
MGTNE60	60	12	M8	15	28	64.5	362	160	Ni,Zn,Epoxy or Customized
MGTNE70	70	17	M10	17	34	80	566	200	Ni,Zn,Epoxy or Customized
MGTNE75	75	17	M10	18	35	81	681	270	Ni,Zn,Epoxy or Customized
MGTNE80	80	17	M10	18	35	81	761	300	Ni,Zn,Epoxy or Customized
Note: Dimension can be customized, contact us for more details and informaiton.

Note

We have hundreds of types magnetic assemblies, including fishing magnet, pot magnet, magnetic lifter, magnetic filter, office magnet, magnetic coupling, magnetic rotor, magnetic stator and customized parts. Contact us freely if you have any inquiry.

• The company was established in 2014 and its registered address is Qingdao, China
• The company's main products are: Rare earth metals, Rare earth magnetic powder, Rare earth NdFeB Compound, Rare earth Samarium-Iron-Nitrogen Compound, Various magnetic materials: Bonded NdFeB Magnets,Injection molding NdFeB Magnets, Injection molding SmFeN Magnets,Sintered NdFeB Magnets, magnetic Assemblies;
• The current annual sales are 20-25 million RMB or 3-4 million US dollars
• Magnetic powder and rare earth metal sales accounted for 50%; Particles and magnetic materials accounted for 30%; Magnetic Assemblies: 20%
• We have R&D and manufacturing capabilities from rare earth magnetic powder to magnetic materials
• At present, we provide high-quality products to customers in China, Japan, Korea, Germany and other countries.
